Battery Status

• _{06 Dec 00:43}
  Version 1.0.0

  Note: Thanks to Morphik and his Comment, i was able to change the Font also with the script,
  because of that, i uploaded a new version.

  Note Update 29.12.17: Both Versions are now the same new Version, since i understand how to update my Workshop
  projects

  This script shows Battery level and states on standart LCD, Textpanels or Wide LCD, as digital Symbols.
  [Vanilla / No Mods needed]

  Installation:
  Just add this NameTag "[Battery Status LCD]" to your LCD, and all LCD's you want,
  example: My LCD Name [Battery Status LCD]. and put Font to "Monospace".

  Then just put my script in a Programmable Block, edit your settings, save + compile.
  Ready to use.

  There is also an Demo-Wold, here's the link:
  http://steamcommunity.com/sharedfiles/filedetails/?id=1222790810

  There a some Settings you can edit, i explain them below. Or you watch my Tutorials on YT.
  https://youtu.be/tSCpOraoRJ8

  Hope you enjoy it.

  Available Settings / Options:

  ----- Generals -----
  All LCD with a specific NameTag included in their name, will be show the information. You can edit the NameTag.
  string LCD_NameTag = "[Battery Status LCD]"; example: my LCD 31 [Battery Status LCD]

  On default this script search for all Battery's attached, but somethimes you want be able to show
  only specific Battery's bool false = show all found Battery's attached,
  true = show only Battery's with Specific NameTag in their name

  that means that only Battery's with this NameTag added to your Battery Blockname, will be shown.
  you can change the Nametag also.
  string BatteryNameTag = "[Battery-Status]"; example: my Battery 15 [Battery-Status]

  ----- Display Settings -----
  LCD or Wide LCD
  on default it shows a total amount of max. 50 Battery's. There's a option to show a total amount of 100 Battery's,
  but this only works for wide LCDs, Note: on 1x1 LCD will be then shown just the half information!
  bool WideLCD = false; true = 50 Battery's
  false = Show on wide LCD's up to 100 Battery's

  This script change size of the Symbols depending of the amount.
  it shows Large Symbols for an total amount of 1-10 Battery's on 1x1 LCDs, and a total amount of 1-20 Battery's on wide LCDs, all amount above will be shown in small Symbols, to show always small Symbols.
  bool OnlySmallSigns_Enabled = false; true = always small symbols
  false = depending on amount

  Self updating System
  Thanks to SpaceEngineers Update 1.185.1, we are able to use a new system, no need for timer,
  bool SelfUpdatingSys_Enabled = true; false = Off, need an activation
  true = after compile, script Selfupdating starts

  If Self updating System enabled you can choose how many times per second the script will be activated int SelfUpSys_perSec 1 = 1 sec
  2 = 2 sec etc.

  ----- Other Settings -----
  Shows Title on top of the LCD / Text Panel
  "BATTERY STATUS" as title on Top, if disabled it leaves the space black
  bool BatteryTitle_Enabled = true; true = show title
  false = no title

  There are three lines as border, you can deaktivate each of them of you want, true = on, false = off
  bool Underline_1_Enabled = true; Show Underline below Title
  bool BatSpaceline_Enabled = true; Show Middle line between Battery Amount and Stored Energy
  bool Underline_2_Enabled = true; Show Underline Below Battery Amount and Stored Energy

  Show Amount of Battery's displayed
  bool BatteryAmountEnabled = true; true = Show Amount
  false = off

  Show total amount of all Stored Energy in Wh, kWh, MWh or GWh, Units depending on amount of Energy
  bool BatteryAllStoredEnergyEnabled = true; true = Show stored Energy
  false = off

  Show Status of Power Input with an small Flash-Symbol
  when no Power input = red Reactor
  Solar Panel online and no reactor
  Power Input below needed supply = Orange

  bool PowerInput_Enabled = true; true = Show Power supply as Flash-Symbol, changes color
  false = off

  LCD Brightness
  0-255, 0 = dark, 255 = Bright
  int LCDbright = 255;

  ----- Kown Problems -----
  if you placeing a SolarPanel, it stops the script, recompile, and it will run again.

  Special Thanks to YouTuber Splitsie for presenting the Converter script on YT, and big Thanks to
  Speedy Gonzales that made the converter, because of that i was able to made this awesome script.

  And General Thanks to the Community, to all that share their knowledge, that helped me a lot to make this
  scripts working. To all thanks for that.
